Built with React and Tailwind. Copy the prompt and paste it into Claude Code, Cursor or Lovable: your agent adds animated pattern cloud to your project and fits it to your theme.

Code

How animated pattern cloud is used: the demo's code. The component's own source comes with a free account.

Usage.tsx

import React, { useEffect, useRef } from 'react';

/**
 * ProceduralGroundBackground
 * A WebGL 2D background featuring topographic neon lines and sand-ripple movement.
 * Optimized for performance using fragment shaders.
 */
const ProceduralGroundBackground: React.FC = () => {
  const canvasRef = useRef<HTMLCanvasElement>(null);

  useEffect(() => {
    const canvas = canvasRef.current;
    if (!canvas) return;

    const gl = canvas.getContext('webgl');
    if (!gl) return;

    const vsSource = `
      attribute vec2 position;
      void main() {
        gl_Position = vec4(position, 0.0, 1.0);
      }
    `;

    const fsSource = `
      precision highp float;
      uniform float u_time;
      uniform vec2 u_resolution;

      float hash(vec2 p) {
        return fract(sin(dot(p, vec2(127.1, 311.7))) * 43758.5453123);
      }

      float noise(vec2 p) {
        vec2 i = floor(p);
        vec2 f = fract(p);
        vec2 u = f * f * (3.0 - 2.0 * f);
        return mix(mix(hash(i + vec2(0.0, 0.0)), hash(i + vec2(1.0, 0.0)), u.x),
                   mix(hash(i + vec2(0.0, 1.0)), hash(i + vec2(1.0, 1.0)), u.x), u.y);
      }

      void main() {
        vec2 uv = (gl_FragCoord.xy * 2.0 - u_resolution.xy) / min(u_resolution.x, u_resolution.y);

        // Ground Perspective Simulation
        float depth = 1.0 / (uv.y + 1.15);
        vec2 gridUv = vec2(uv.x * depth, depth + u_time * 0.15);

        // Layered Procedural Noise for Terrain
        float n = noise(gridUv * 3.5);
        float ripples = sin(gridUv.y * 18.0 + n * 8.0 + u_time * 0.5);

        // Neon Topographic Lines
        float topoLine = smoothstep(0.03, 0.0, abs(ripples));

        // Color Palette
        vec3 baseColor = vec3(0.04, 0.03, 0.12); // Deep Space
        vec3 accentColor = vec3(0.1, 0.3, 0.8);   // Electric Blue
        vec3 neonColor = vec3(0.6, 0.2, 1.0);     // Neon Purple

        // Composite
        vec3 finalColor = mix(baseColor, accentColor, n * 0.6);
        finalColor += topoLine * neonColor * depth * 0.4;

        // Horizon Fog / Fade
        float fade = smoothstep(0.1, -1.0, uv.y);
        finalColor *= (1.0 - length(uv) * 0.45) * (1.0 - fade);

        gl_FragColor = vec4(finalColor, 1.0);
      }
    `;

    const createShader = (gl: WebGLRenderingContext, type: number, source: string) => {
      const shader = gl.createShader(type)!;
      gl.shaderSource(shader, source);
      gl.compileShader(shader);
      return shader;
    };

    const program = gl.createProgram()!;
    gl.attachShader(program, createShader(gl, gl.VERTEX_SHADER, vsSource));
    gl.attachShader(program, createShader(gl, gl.FRAGMENT_SHADER, fsSource));
    gl.linkProgram(program);
    gl.useProgram(program);

    const buffer = gl.createBuffer();
    gl.bindBuffer(gl.ARRAY_BUFFER, buffer);
    gl.bufferData(gl.ARRAY_BUFFER, new Float32Array([
      -1, -1,  1, -1, -1,  1,
      -1,  1,  1, -1,  1,  1
    ]), gl.STATIC_DRAW);

    const posAttrib = gl.getAttribLocation(program, "position");
    gl.enableVertexAttribArray(posAttrib);
    gl.vertexAttribPointer(posAttrib, 2, gl.FLOAT, false, 0, 0);

    const timeLoc = gl.getUniformLocation(program, "u_time");
    const resLoc = gl.getUniformLocation(program, "u_resolution");

    let animationFrameId: number;
    const render = (time: number) => {
      const { innerWidth: width, innerHeight: height } = window;
      if (canvas.width !== width || canvas.height !== height) {
        canvas.width = width;
        canvas.height = height;
        gl.viewport(0, 0, width, height);
      }

      gl.uniform1f(timeLoc, time * 0.001);
      gl.uniform2f(resLoc, width, height);
      gl.drawArrays(gl.TRIANGLES, 0, 6);
      animationFrameId = requestAnimationFrame(render);
    };

    animationFrameId = requestAnimationFrame(render);

    return () => {
      cancelAnimationFrame(animationFrameId);
    };
  }, []);

  return (
    <div className="fixed inset-0 w-full h-full bg-zinc-950 -z-10">
      <canvas
        ref={canvasRef}
        className="w-full h-full block touch-none"
        style={{ filter: 'contrast(1.1) brightness(0.9)' }}
      />
    </div>
  );
};

export default ProceduralGroundBackground;
