About

A React Flow handle for node inputs/outputs that lets users add, rename, describe, and delete handles inline via a popover editor.

Built with React and Tailwind. Copy the prompt and paste it into Claude Code, Cursor or Lovable: your agent adds Editable Handle to your project and fits it to your theme.

Code

How Editable Handle is used: the demo's code. The component's own source comes with a free account.

Usage.tsx

"use client";

import "@xyflow/react/dist/style.css";

import {
  addEdge,
  applyEdgeChanges,
  applyNodeChanges,
  Background,
  type Connection,
  type EdgeChange,
  type Node,
  type NodeChange,
  type NodeProps,
  type NodeTypes,
  Position,
  ReactFlow,
  ReactFlowProvider,
  useUpdateNodeInternals,
} from "@xyflow/react";
import { nanoid } from "nanoid";
import { useCallback, useState } from "react";
import { Button } from "@/components/ui/button";
import {
  EditableHandle,
  EditableHandleDialog,
} from "@/components/ui/editable-handle";

const DynamicHandlesNode = ({ id }: NodeProps<Node>) => {
  const updateNodeInternals = useUpdateNodeInternals();
  const [handles, setHandles] = useState<
    { id: string; name: string; description?: string }[]
  >([
    {
      id: "1",
      name: "input1",
      description: "Input 1 description",
    },
  ]);

  const handleCreate = useCallback(
    (name: string, description?: string) => {
      const newHandle = {
        id: `handle-${nanoid()}`,
        name,
        description,
      };
      setHandles((prev) => [...prev, newHandle]);
      updateNodeInternals(id);
      return true;
    },
    [id, updateNodeInternals],
  );

  const handleUpdate = useCallback(
    (handleId: string, newName: string, newDescription?: string) => {
      setHandles((prev) =>
        prev.map((handle) =>
          handle.id === handleId
            ? {
                ...handle,
                name: newName,
                description: newDescription,
              }
            : handle,
        ),
      );
      return true;
    },
    [],
  );

  const handleDelete = useCallback(
    (handleId: string) => {
      setHandles((prev) => prev.filter((handle) => handle.id !== handleId));
      updateNodeInternals(id);
    },
    [id, updateNodeInternals],
  );

  return (
    <div className="py-4 border rounded-lg bg-background w-[300px]">
      <h2 className="text-lg font-semibold mb-4 px-4">
        Node with dynamic Handles
      </h2>

      <EditableHandleDialog
        variant="create"
        label=""
        onSave={handleCreate}
        onCancel={() => {}}
        align="start"
      >
        <Button variant="outline" size="sm" className="h-8 ml-4">
          Create New Handle
        </Button>
      </EditableHandleDialog>

      <div className="mt-4 space-y-2">
        {handles.map((handle) => (
          <div key={handle.id} className="flex items-center gap-2">
            <EditableHandle
              nodeId={id}
              handleId={handle.id}
              name={handle.name}
              description={handle.description}
              type="target"
              position={Position.Left}
              wrapperClassName="w-full"
              onUpdateTool={handleUpdate}
              onDelete={handleDelete}
            />
          </div>
        ))}
      </div>
    </div>
  );
};

const nodeTypes: NodeTypes = {
  "editable-handle-node": DynamicHandlesNode,
};

const initialNodes = [
  {
    id: "node-1",
    type: "editable-handle-node",
    position: { x: 0, y: 0 },
    data: {},
  },
];

export default function EditableHandleDemo() {
  const [nodes, setNodes] = useState<Node[]>(initialNodes);
  const [edges, setEdges] = useState([]);

  const defaultViewport = { x: 100, y: 150, zoom: 1.1 };

  const onNodesChange = useCallback(
    (changes: NodeChange<Node>[]) =>
      setNodes((nds) => applyNodeChanges(changes, nds)),
    [],
  );
  const onEdgesChange = useCallback(
    (changes: EdgeChange<never>[]) =>
      setEdges((eds) => applyEdgeChanges(changes, eds)),
    [],
  );
  const onConnect = useCallback(
    (connection: Connection) => setEdges((eds) => addEdge(connection, eds)),
    [],
  );

  return (
    <div className="w-full h-screen">
      <ReactFlowProvider>
        <ReactFlow
          nodes={nodes}
          edges={edges}
          onNodesChange={onNodesChange}
          onEdgesChange={onEdgesChange}
          onConnect={onConnect}
          nodeTypes={nodeTypes}
          defaultViewport={defaultViewport}
        >
          <Background />
        </ReactFlow>
      </ReactFlowProvider>
    </div>
  );
}
