Sean Hello

Line Charts 2

Cards 193

About

Line charts designed to present key metrics and insights. Each chart features unique layouts, data visualizations, and styling options. Perfect for dashboards, admin panels, and analytics pages.

Built with React and Tailwind. Copy the prompt and paste it into Claude Code, Cursor or Lovable: your agent adds Line Charts 2 to your project and fits it to your theme.

Code

How Line Charts 2 is used: the demo's code. The component's own source comes with a free account.

Usage.tsx

'use client';

import React, { useState } from 'react';
import { Badge } from '@/components/ui/badge-2';
import { Card, CardContent, CardHeader, CardTitle, CardToolbar } from '@/components/ui/card';
import { ChartConfig, ChartContainer, ChartTooltip } from '@/components/ui/line-charts-2';
import { Select, SelectContent, SelectItem, SelectTrigger } from '@/components/ui/select';
import { TrendingUp } from 'lucide-react';
import { Area, CartesianGrid, ComposedChart, Line, XAxis, YAxis } from 'recharts';

// Cashflow data for 12 months
const cashflowData = [
  { month: 'JAN', value: 2100 },
  { month: 'FEB', value: 2300 },
  { month: 'MAR', value: 1900 },
  { month: 'APR', value: 4800 },
  { month: 'MAY', value: 5200 },
  { month: 'JUN', value: 8900 },
  { month: 'JUL', value: 6200 },
  { month: 'AUG', value: 7100 },
  { month: 'SEP', value: 9400 },
  { month: 'OCT', value: 10200 },
  { month: 'NOV', value: 11100 },
  { month: 'DEC', value: 11800 },
];

// Use custom or Tailwind standard colors: https://tailwindcss.com/docs/colors
const chartConfig = {
  value: {
    label: 'Cashflow',
    color: 'var(--color-violet-500)',
  },
} satisfies ChartConfig;

// Custom Tooltip
interface TooltipProps {
  active?: boolean;
  payload?: Array<{
    dataKey: string;
    value: number;
    color: string;
  }>;
  label?: string;
}

const CustomTooltip = ({ active, payload }: TooltipProps) => {
  if (active && payload && payload.length) {
    return (
      <div className="w-full max-w-5xl min-h-screen flex items-center justify-center p-6 lg:p-8">
        <div className="rounded-lg bg-zinc-900 text-white p-3 shadow-lg">
          <div className="text-xs font-medium mb-1">Total:</div>
          <div className="text-sm font-semibold">${payload[0].value.toLocaleString()}</div>
        </div>
      </div>
    );
  }
  return null;
};

// Period configuration
const PERIODS = {
  '6m': {
    key: '6m',
    label: '6 months',
    dateRange: 'Jul 01 - Dec 31, 2024',
  },
  '12m': {
    key: '12m',
    label: '12 months',
    dateRange: 'Jan 01 - Dec 31, 2024',
  },
  '2y': {
    key: '2y',
    label: '2 years',
    dateRange: 'Jan 01, 2023 - Dec 31, 2024',
  },
} as const;

type PeriodKey = keyof typeof PERIODS;

export default function LineChart2() {
  const [selectedPeriod, setSelectedPeriod] = useState<PeriodKey>('12m');

  // Filter data based on selected period
  const getFilteredData = () => {
    switch (selectedPeriod) {
      case '6m':
        return cashflowData.slice(-6);
      case '12m':
        return cashflowData;
      case '2y':
        // Simulate 2 years data by duplicating and modifying the current year
        const previousYear = cashflowData.map((item) => ({
          month: `${item.month} '23`,
          value: Math.round(item.value * 0.85), // 15% lower for previous year
        }));
        const currentYear = cashflowData.map((item) => ({
          month: `${item.month} '24`,
          value: item.value,
        }));
        return [...previousYear, ...currentYear];
      default:
        return cashflowData;
    }
  };

  const filteredData = getFilteredData();

  // Get current period configuration
  const currentPeriod = PERIODS[selectedPeriod];

  // Calculate total and percentage based on filtered data
  const totalCash = filteredData.reduce((sum, item) => sum + item.value, 0);
  const lastValue = filteredData[filteredData.length - 1]?.value || 0;
  const previousValue = filteredData[filteredData.length - 2]?.value || 0;
  const percentageChange = previousValue > 0 ? ((lastValue - previousValue) / previousValue) * 100 : 0;

  return (
    <div className="w-full max-w-5xl min-h-screen flex items-center justify-center p-6 lg:p-8">
      <Card className="w-full lg:max-w-4xl ">
        <CardHeader className="border-0 min-h-auto pt-6 pb-4">
          <CardTitle className="text-lg font-semibold">Cashflow</CardTitle>
          <CardToolbar>
            <Select value={selectedPeriod} onValueChange={(value) => setSelectedPeriod(value as PeriodKey)}>
              <SelectTrigger>{currentPeriod.label}</SelectTrigger>
              <SelectContent align="end">
                {Object.values(PERIODS).map((period) => (
                  <SelectItem key={period.key} value={period.key}>
                    {period.label}
                  </SelectItem>
                ))}
              </SelectContent>
            </Select>
          </CardToolbar>
        </CardHeader>

        <CardContent className="px-0">
          {/* Stats Section */}
          <div className="px-5 mb-8">
            <div className="text-xs font-medium text-muted-foreground tracking-wide mb-2">
              {currentPeriod.dateRange}
            </div>
            <div className="flex items-center gap-3 mb-4">
              <div className="text-3xl font-bold">${totalCash.toLocaleString()}</div>
              <Badge variant="success" appearance="light">
                <TrendingUp className="size-3" />
                {Math.abs(percentageChange).toFixed(2)}%
              </Badge>
            </div>
          </div>

          {/* Chart */}
          <div className="relative">
            <ChartContainer
              config={chartConfig}
              className="h-[300px] w-full ps-1.5 pe-2.5 overflow-visible [&_.recharts-curve.recharts-tooltip-cursor]:stroke-initial"
            >
              <ComposedChart
                data={filteredData}
                margin={{
                  top: 25,
                  right: 25,
                  left: 0,
                  bottom: 25,
                }}
                style={{ overflow: 'visible' }}
              >
                {/* Gradient */}
                <defs>
                  <linearGradient id="cashflowGradient" x1="0" y1="0" x2="0" y2="1">
                    <stop offset="0%" stopColor={chartConfig.value.color} stopOpacity={0.15} />
                    <stop offset="100%" stopColor={chartConfig.value.color} stopOpacity={0} />
                  </linearGradient>
                  <filter id="dotShadow" x="-50%" y="-50%" width="200%" height="200%">
                    <feDropShadow dx="2" dy="2" stdDeviation="3" floodColor="rgba(0,0,0,0.5)" />
                  </filter>
                </defs>

                <CartesianGrid
                  strokeDasharray="4 12"
                  stroke="var(--input)"
                  strokeOpacity={1}
                  horizontal={true}
                  vertical={false}
                />

                <XAxis
                  dataKey="month"
                  axisLine={false}
                  tickLine={false}
                  tick={{ fontSize: 12 }}
                  tickMargin={12}
                  dy={10}
                />

                <YAxis
                  axisLine={false}
                  tickLine={false}
                  tick={{ fontSize: 12 }}
                  tickFormatter={(value) => `${value / 1000}K`}
                  domain={[0, 'dataMax + 1000']}
                  tickCount={6}
                  tickMargin={12}
                />

                <ChartTooltip
                  content={<CustomTooltip />}
                  cursor={{
                    stroke: chartConfig.value.color,
                    strokeWidth: 1,
                    strokeDasharray: 'none',
                  }}
                />

                {/* Gradient area */}
                <Area
                  type="linear"
                  dataKey="value"
                  stroke="transparent"
                  fill="url(#cashflowGradient)"
                  strokeWidth={0}
                  dot={false}
                />

                {/* Main cashflow line */}
                <Line
                  type="linear"
                  dataKey="value"
                  stroke={chartConfig.value.color}
                  strokeWidth={3}
                  dot={(props) => {
                    const { cx, cy, payload } = props;
                    if (payload.month === 'JUN' || payload.month === 'NOV') {
                      return (
                        <circle
                          key={`dot-${cx}-${cy}`}
                          cx={cx}
                          cy={cy}
                          r={6}
                          fill={chartConfig.value.color}
                          stroke="white"
                          strokeWidth={2}
                          filter="url(#dotShadow)"
                        />
                      );
                    }
                    return <g key={`dot-${cx}-${cy}`} />; // Return empty group for other points
                  }}
                  activeDot={{
                    r: 6,
                    fill: chartConfig.value.color,
                    stroke: 'white',
                    strokeWidth: 2,
                    filter: 'url(#dotShadow)',
                  }}
                />
              </ComposedChart>
            </ChartContainer>
          </div>
        </CardContent>
      </Card>
    </div>
  );
}
